Battery scientists make a cracking observation

Scientists at the Georgia Institute of Technology in the U.S. used x-ray imaging to observe cracks forming in a solid state lithium battery, a discovery they say changes the understanding of performance of solid state batteries and which could lead to more durable systems.

July 2, 2019 Mark Hutchins

Researchers at Georgia Tech made the breakthrough.

Image: Hector Alejandro/Flickr

From pv magazine global.

The potential for solid state batteries to provide a safer and smaller alternative to today’s lithium-ion technologies is well known and research groups worldwide are working to overcome issues that hold the technology back from commercial adoption.

A discovery made by scientists at the Georgia Institute of Technology could help move such research in the right direction. The team built a solid-state battery with a solid ceramic layer as electrolyte between two layers of lithium. They then used x-ray computed tomography – a technique similar to the CT scans used in medicine – to observe its behavior and degradation during charging and discharging.

“Figuring out how to make these solid pieces fit together and behave well over long periods of time is the challenge,” said Matthew McDowell, assistant professor in the George W. Woodruff School of Mechanical Engineering and the School of Materials Science and Engineering. “We’re working on how to engineer these interfaces between these solid pieces to make them last as long as possible.”

Cracks appeared

The results, published in the paper Visualizing Chemomechanical Degradation of a Solid-State Battery Electrolyte, in the journal ACS Energy Letters, illustrated how cracks began to form in the electrolyte layer over a few days, causing increased resistance to ion flow.

Previously, said McDowell, it was thought chemical reactions at the interface between the lithium metal and electrolyte were the cause of degradation in the battery, rather than cracking in the cells.

“What we learned by doing this imaging is that in this particular material it’s not the chemical reactions themselves that are bad – they don’t affect the performance of the battery,” he added. “What’s bad is that the cell fractures and that destroys the performance of the cell.”

The researchers say their discovery is likely to also apply to alternative solid-state battery chemistries and could help influence further research into the creation of durable concepts for the promising technology.

“In normal lithium-ion batteries the materials we use define how much energy we can store,” McDowell said. “Pure lithium can hold the most but it doesn’t work well with liquid electrolyte. But if you could use solid lithium with a solid electrolyte that would be the holy grail of energy density.”
